Single Arch or Double Arch: Dentate Against Dentate

• Photographs: full face full smile photo, profile photo if Class II or III, and retracted photographs – front, left side, right side.
• CBCT patient open biting on co on rolls. Place co on rolls between cheeks and teeth.
• Maxillary and mandibular master casts or impressions. Must capture vestibule of the CHROME.
• CO or CR bite registration.
• Full Rx completed when uploading DICOM and photos.

Single Arch: Dentate Against Denture

If Single Guide is the dentate arch:

• Photographs: Full face full smile photo, profile photo if Class II or III, and retracted photographs – front, left side, right side.
• Master casts or impression of dentate arch (must capture vestibule), and impression of denture teeth and tissue.
• Place 6 radiopaque markers on the denture (SureMark.com, or gutta percha 2mm round). CBCT patient open biting on cotton rolls.–OUT OF OCCLUSION.
• CO or CR bite registration.
• Full Rx completed when uploading DICOM and photos.

If Single Guide is the denture arch:

• Photographs: Full face full smile photo, profile photo if Class II or III, and retracted photographs – front, left side, right side.
• Master casts or impression of dentate arch (must capture vestibule), and impression of denture teeth and tissue.
• Place 6 radiopaque markers on the denture (SureMark.com, or gutta percha 2mm round). CBCT patient open biting on cotton rolls.–OUT OF OCCLUSION.
• CO or CR bite registration.
• Full Rx completed when uploading DICOM and photos.

Double Arch Edentulous

• Photographs: full face full smile photo, profile photo if Class II or III, and retracted photographs – front, left side, right side.
• Place 6 radiopaque markers on the denture (SureMark.com, or gutta percha 2 mm round). CBCT patient open biting on cotton rolls.
• Bite should be worked out in the denture fabrication. If not, maximum opening of bite is 2mm.
• Full Rx completed when uploading DICOM and photos.

Existing Metal Partial Denture in Single Arch

• Metal frames cause scatter and must be removed for the CBCT. If partial is needed for establishing bite, capture in an impression. If not, send master casts, opposing and bite.

Free-end Case With Unstable Bite

• The bite must be established through bite blocks and set-ups. Once the case can be articulated then CHROME can move forward.
